FDS molecular vacuum pump system is ultra-high vacuum equipment, which adopting molecular vacuum pump and dry vacuum pump or double stages rotary vane vacuum pump in series, equipped with pre-pipeline, vacuum valves, molecular vacuum pump power, control box and composite vacuum gauge. Widely used in surface analysis, accelerator technology, semiconductor equipment, plasma technology, electric vacuum device manufacturing and vacuum technology.
Company Name :
Shanghai AFAPA Vacuum Equipment Co., ltd.Brand :
AFAPAAfaPa Vacuum founded in 2004, is one of leading manufacturer of dry (oil-free) and eco-friendly vacuum pumps in China.
The company is a high-tech enterprise led by senior managers, engaged in the manufacturing and R&D of vacuum pumps, engineering and technical services withthe most up to date advanced technologies. Currently, the company owns nearly twenty patents and has gainedthe certification of CE and ISO9000 quality management system.
Our Enterprise Purpose:
1). Green Vacuum: eco-friendly vacuum technology.
2). Professional Vacuum: performed by engineers team.
3). Vacuum solution: provider of technology.
AfaPa company has its sales and service center in Shanghai and has established two bases in Yangzhou and Yancheng, Jiangsu Province.
AfaPa owns high-precision production equipment such as variety of CNC, and has high performance testing equipment such as 3D measuring machine, helium mass spectrometer vacuum leak detector, comprehensive test platform etc.
AfaPa company has good reputation among our customers at home and abroad.
①DPS Air-cooled Dry Compound Screw Vacuum Pump
First Air Cooled Dry Variable Pitch Screw Vacuum Pump
DPS dry compound screw vacuum pump is the innovation and development of AfaPa’s products, using the fifth generation of compound variable pitch screw technology (30% energy saving, low exhaust temperature), with high efficiency, energy saving, environmental protection, lightweight, easy operation, reliable performance characteristics. It will be main developing trend of the vacuum pump in future.
②DCP Dry Claw Vacuum Pump
DCP Vacuum Pump is a high cost-effective environmental protection vacuum pump by self-dependent innovation and develop,which base on numerous foreign vacuum pump.
③DPSB Dry Screw Vacuum Pump (System) with Box
DPSB dry screw vacuum pump(system) with box is a new type vacuum system, it is designed and developed as customer requirements, including vacuum pump, frequency conversion governor, digital display vacuum gauge, cooling fan, metal frame, metal plate and other related components.
Technical Specifications
|
Model
|
FDS600/20
|
FDS1200/40
|
FDS1600/80
|
|
Main Pump
|
F600/150
|
F1200/200
|
F1600/250
|
|
Backing Pump
|
DV16/30/DPS020
|
DV30/54/DPS050
|
DV54/90/DPS080
|
|
Pump Speed(L/S)
|
＞600
|
＞1200
|
＞1600
|
|
Ultimate Vacuum(Pa)
|
6×10(-6)
|
6×10(-6)
|
6×10(-6)
|
|
Inlet Flange
|
DN150
|
DN200
|
DN250
|
|
Outlet Flange
|
KF40
|
KF40
|
KF50
|
|
Voltage(V/Hz)
|
220±20/50
|
220±20/50
|
220±20/50
|
|
Starting Time(Min)
|
＜5
|
＜5
|
＜5
|
|
Cooling Method
|
Air /water Cooled
|
Air /water Cooled
|
water Cooled
|
|
Weight(Kg)
|
28
|
32
|
36
|
