Ultrapure Water System Q-STER-G Series (high-end type)

Ultrapure Water System Q-STER-G Series double stage reverse osmosis

273

  • Company Name :

    Hunan Qiqin Environmental Protection Technology Co., Ltd.

  • Brand :

    QiQin

  • Working mode :

    automatic operation

  • Water quality testing :

    online real-time monitoring and display

  • Alarm :

    system failure and consumables replacement reminder and alarm

  • Flushing and circulation :

    automatic flushing and internal circulation

  • Data storage :

    data can be stored and printed
Product Tags : Ultrapure Water System Q-STER-G Series (high-end type) ultrapure water purification system price ultrapure water purifier ultrapure water system for laboratory ultrapure water machine type 1 water plant
Inquire Now
Share To :
Product categories

New Products

More

Technical Articles

More

Hunan Qiqin Environmental Protection Technology Co., Ltd. is located in the historical and cultural city of Changsha, Hunan province of China.

Qiqin is a national high-tech enterprise specialised in research, production, sales, and after-sales service of purified water systems, ultrapure water systems, wastewater treatment systems for laboratories, hospitals and biopharmaceuticals.

As a professional manufacturer of water treatment equipment, the excellent performance of our products is only one of our commitments to customers. We pursue not only technical excellence, but also high standards in service, to provide customers with excellent experience.

Qiqin is not only a practitioner of environmental sustainable development, but also an active promoter of this concept. Based on innovative technologies, we constantly explore the path of development in water treatment industry, achieving a win-win for both environmental protection and the economy.

1. Ultrapure Water System for Laboratory

2. Pure Water System for Hospital

3. Purified Water System for Biopharmaceuticals

3. Ultrapure Water System for Semiconductor Industry

4. Waste Water Treatment System for laboratory and hospital

More Information

The system adopts pretreatment and two-stage reverse osmosis configuration to produce lab type ll water qualty, combined with theutra-purifcation module to obtain ultrapure water with resistivity 18.25M0.cm (25 c), The periect process and svstem peromance issutable to a vareiv ot complex water sources, and the produced water can meet varous expenmenta reaulrements. tis the best cholcefor high-end laboratory users.

Water production 10L/H-60L/H.



System features and advantages

  • ABS integrated molding engineering plastics are used to eliminate corosion and rust.
  • The 5-inch large touch color screen operation interface displays the real-time operation status and watelquality is fully monitored. it has a USB interface, which supports data copying, downloading, printing.storage. it automatically record water quality data for five years to help laboratory data statistics.
  • Online 3-channel water quality monitoring, re altime monitoring of raw water/RO water, RO water/EDl purewater, UP ultrapure water quality, and can also detect water temperature, TOC value, water tank level andother data .
  • Fully automatic RO membrane anti-scale rinsing procedure to prolong the service life of RO membrane.
  • The ultrapure water circulation system can be started and shut down freely, maintaining a low level ofbacterial contamination in the system.
  • Two-evels passwords to factory and user, system settings are protected by passwords to prevent unauthorized changes.
  • The lifetime of pretreatment, RO membrane, UV lamp and ultra-purification column can be set, showingthe used and remainina time of consumables, and automatic reminders when consumables are due to bereplaced to avoid water quality degradation.
  • Metered water intake function (timing: 1-60 liters).
  • Pretreatment, RO membrane, and ultra-purification components adopt a modular independent structurewhich makes system maintenance and filter element replacement more convenient, and conforms to GLFspecifications. Using DOW original imported RO membrane and DOW ultra-purification resin, the combination of long life of RO membrane and high-quality water quality is realized.
  • Dual-wavelength(185nm&254nm)UV lamp assembly (importedlamp)can effectively sterilize, reduce TOC, and enhance thescope of application of the system.
  • 5000DUF ultrafiltration assembly (original imported), effectivelyremove pyrogen(endotoxin), can be used for precision cellculture and IVF.
  • (0.45+0.1)um imported PES polyethersulfone composite membraneterminal sterilization filter to ensure water quality sterility.
  • QlQlN water tank is integrally molded with sanitary non-transparentplastic, top air filter, three-stage liquid level control and ultravioletsterilization of the water tank to strictly control growth of bacteria in thewater tank.
