Three-effect Forced CirculationCrystallization Evaporator

69

Company Name :
YAN JIALONG MECHANICAL TECHNOLOGY(JIANGSU)CO.,LTD.
Brand :
Yanjialong Technology

Product Tags : Three-effect Forced CirculationCrystallization Evaporator forced evaporator effect evaporator forced circulation type evaporator forced circulation evaporator uses

Inquire Now

Share To :

Product categories

New Products

More

Technical Articles

More

Company Introduction
Main Products

Yanjialong Machinery Technology (Jiangsu) Co., Ltd. is a service provider focusing on evaporation (concentration) crystallization equipment. Adhering to the beautiful vision of "recycling every drop of water", we have always focused on the research and development, design and manufacturing of evaporator technology products, and have an experienced technical team.

Yanjialong is currently a high-tech evaporator enterprise with a full range of pilot equipment for multi-effect evaporators, falling film evaporator pilot equipment, and MVR evaporator pilot equipment in China. At present, the company has a relatively large evaporator R&D and production base, with its own production workshop and laboratory test equipment, which can conduct material analysis for customers in a timely manner.

Yanjialong Company has more than 10 years of engineering experience and performance in testing, design, processing, installation, commissioning and after-sales service, with a technical team of more than 30 people. The company has obtained a number of high-tech enterprise certificates through the ISO9001 quality certification system, and has a number of patents for various inventions and utility models, many of which have reached the domestic forefront level, the company is committed to making the water clearer, the sky bluer, and the environment more beautiful.

MVR Evaporator,
Multi-effect Evaporator,
Bring Drying Machine, Single-effect Evaporator,
Film Scraper Evaporator

More Information

Application

Three-effect forced circulation evaporator is suitable for evaporation and concentration in chemical, food, pharmaceutical, waste liquid evaporation and recovery industries with scaling, crystalline, heat-sensitive (low temperature), high concentration, high viscosity and containing insoluble solids.

Features

The equipment has a wide range of adaptation to the characteristics of the materials processed by the equipment. Among them, it is mainly aimed at materials that are easy to scale during the evaporation process, materials with crystal precipitation during the evaporation process, materials whose viscosity increases with the increase of concentration concentration, and materials with insoluble solids.
During the evaporation process, the material heats up through forced circulation, which flows fast in the tube, heats evenly, has a high heat transfer coefficient, and can prevent dry walls.
The material liquid is quickly heated by the heater through the forced circulation pump, and the top comes out directly into the evaporation separator in a tangential manner, and the vapor-liquid separation effect is good.
The material is evaporated and concentrated by equipment, vacuum and low-temperature evaporation and concentration, plus continuous feeding and discangulation, the heating and evaporation time is short, which is suitable for the heat-sensitive evaporation and concentration of food sauce materials.
The equipment has a compact structure, a small footprint, smooth layout, easy operation, and stable performance.
The equipment can be configured with an automation system to realize automatic screwing of feed volume, automatic control of heating temperature, automatic control of discharge concentration, and can also be equipped with automatic operation and control such as sudden power outage and protection measures for sensitive materials in case of fault, and other alarms.
