LW Operating principle

Separation takes place in a horizontal bowl equipped with a scroll conveyorThe process material is fed into the bowl through a stationary inlet tube and is smoothly accelerated in the accelerate chamber Centrifugal forces cause instant sedimentation of the solids on the wall of the bowl. The conveyor rotates in the same direction as the bowl, but at a different speed, thus moving the solids towards the conical end of the bowl.

LW Applications

• Industrial and municipal wastewater treatment
• Oil & gas drilling mud/fluid control
• Washing, classification and dewatering of amylm and starch
• Mycelium separation from zymotic fluid of antibiotic
• Dewatering of soybean and wheat protein
• Dewatering ol fish power and tish meet
• Dewatering of grains
• Clarification and extraction of fruit juice
• Clarification and pu rification for animal and vegetable oil
• Production and extraction of olive oil, palm oil, avocado oil
• Separation and purification for coal tar
• Grading of kaolin and graphite
• Classification and dewatering for dyestuff and pigment
• Float wash of extractive coal and dewatering of coal mud
• Classification and dewatering for minerals

LW Main constructional features

• Vertical base design and symmetrical arrangement of motor and bowl assembly that ensures stable operation and less vibration
• Main parts such as the bowl and conveyor are made of corrosion-resistant stainless steel or duplex steel, offering high maximum bowl speed and high centrifugal force.
• Double motor double frequency control, drum, screw speed are stepless adjustable.
• Screw conveyor flights tiled or lined with ceramic, tungsten carbide, or other hard alloys.
• Planetary gear and hydraulic differential two structural options, the difference adjustment range is large, for different solid phase push torque transmission.
• Multiple safety protection: bowl speed and differential speed detection, over-vibration protection, motor overload and overheat protection, bearing temperature monitoring, conveyor torque protection and gas-tight explosion-proof protection.
• Special shock absorber, fixed without anchor bolt.

LW Wear Protection

1. Scroll with welded hard facing or spray coating
2. Scroll inlaid with tungsten carbide tiles
3. Bowl inner wall welding with high strength wear resistant strips

1. Tungsten carbide or ceramic bushings
2. Simple structure and easily replacement
3. Low maintenance cost

1. Auxiliary motor component
2. Differential
3. External rotating drum components
4. Internal screw unit
5. Casing component
6. Feed pipe
7. Bearing block
8. Main motor component
9. Frame component
10. Discharge opening
11. Liquid outlet
12. Shock absorber

LW Standard Type Decanter Centrifuge

Labyrinth seal is used for both bowl ends of LW standard type decanter centrifuge, simple and convenient, after separation, the solid phase is conveyed to the solid discharge port by scroll conveyor, and discharged out of centrifuge under centrifugal force caused by high speed rotation; while the liquid phase drains out under gravity and centrifugal force through the overflow plate. This series decanter centrifuge features easily operation, continuous and stable running, and wide application scope.

LW Technical parameters
